How To: Enable Two-Factor Authentication for Alt TTY and CentOS GNOME GUI Logins

Version Affected: All



Overview

This article explains how to enable two-factor authentication (2FA) on two Linux login surfaces that SecureAuth's Pluggable Authentication Modules (PAM) Remote Authentication Dial-In User Service (RADIUS) installation and configuration guide does not cover on its own: text-based (TTY) console logins, and the CentOS GNOME graphical user interface (GUI) login screen. Complete the PAM RADIUS installation and configuration guide first — the steps below add 2FA to two login paths that guide leaves out.

• Use Method 1 for a text-based console login (TTY).
• Use Method 2 for the CentOS GNOME desktop login screen.



In this article

• Method 1: Enable 2FA for Alt TTY (Console) Logins
• Method 2: Enable 2FA for the CentOS GNOME GUI Login



Method 1: Enable 2FA for Alt TTY (Console) Logins

This method adds the RADIUS-based 2FA prompt to the standard Linux text console login.

1. On the Linux server, open /etc/pam.d/login in a text editor.
2. Set its contents to match the configuration below, which adds pam_radius_auth.so as a sufficient auth module ahead of the standard system-auth substack.



3. Save the file.

After this change, TTY console logins prompt for username, password, and a 2FA code.

Method 2: Enable 2FA for the CentOS GNOME GUI Login

This method adds the RADIUS-based 2FA prompt to the CentOS GNOME desktop login screen.

1. On the Linux server, open /etc/pam.d/gdm-password in a text editor.
2. Set its contents to match the configuration below, which adds pam_radius_auth.so as a required auth module ahead of the optional GNOME keyring module and the standard password-auth substack.



3. Save the file.

After this change, the GNOME GUI login screen prompts for username, password, and a 2FA code.



Special Considerations

Both configurations above were tested on CentOS 7 and CentOS 8.
