How To: Understand How the SecureAuth RADIUS Server Processes Client Rules

Version Affected: All



Overview

The SecureAuth RADIUS Server can have multiple RADIUS Client rules configured, each matching a specific IP address, an IP range, or a wildcard. This article explains the order those rules are evaluated in, so a rule ends up matching the request it was intended for.

How Rules Are Evaluated

Rules are matched in two passes. First, every specific IP address or IP range rule is checked, top to bottom in the order the rules are listed on the RADIUS Clients configuration page — the first specific rule whose IP address or range matches the incoming request's source IP is used. If none of the specific rules match, and a wildcard (*) rule exists anywhere in the list, that wildcard rule is used as a catch-all, regardless of where it appears in the list. If no rule matches at all, including no wildcard rule, the connection is rejected.

For example, consider the following 5 rules, configured in this order:

Given those rules, in this exact order:

1. A request from 10.1.1.86 matches rule 2 (10.1.1.86) exactly, so rule 2 is used.
2. A request from 10.1.1.200 doesn't match any more specific rule, but does match rule 5 (10.1.1.*), so rule 5 is used.
3. A request from 172.16.18.20 doesn't match any more specific rule, but does match rule 4 (172.16.*.*), so rule 4 is used.
4. A request from 172.16.200.36 matches rule 3 (172.16.200.36) exactly, so rule 3 is used.
5. A request from 10.10.10.10 doesn't match any specific rule at all, so it falls through to the wildcard, rule 1 (*).

Special Considerations

Order specific IP or IP-range rules so the most specific rule for any given address comes before less specific ones — for example, an exact IP address before a range that also contains it. A wildcard (*) rule is always evaluated last regardless of where it's placed in the list, so without one, any request that doesn't match a specific rule is rejected.
